Lightweight Log grab - Compact - KLG1-MC

PXL_20220309_085810313

Lightweight Log grab - Compact - KLG1-MC

Designed to be lighter and more compact - specifically for the smaller range of skid steers and mini loaders on the market, including microBull, Giant, Sherpa, Workyquad etc.. But with no compromise on strength - Optional tow bar and capstan (not LOLER rated) The Klou log grab’s rigid swivel system allows it to move logs extremely precisely, and the high build strength and quality ensures reliable performance every day. The Grab features 8 locking positions and free spool - this allows the logs/brash to be dragged more like a trailer The compact version is missing the 'heal' element - allowing a saving in weight and allows for a more compact design, increasing manoeuvrability


Features

    8 Locking positions
    Free Spool
    Optional Capstan Bollard
    Tow bar included
    Variety of hitches available


Specification

Overall Height

505mm

Overall width (open)

1105mm

Overall width (closed)

625

Length

300mm

Max opening

945mm

Min closed dia

60mm

Max log diametre

750

Overall weight

105kg

Max/min flow (l/min)

15/60

Max/min pressure (bar)

150/250
